2025

Starting at $1,799

Ready to use
Setup time: 5-10 minutes
Difficulty: Easy

Performance
Ryzen™ AI 7 350 (Up to 5.0GHz, 8-core
16-thread)

Performance Pro
Ryzen™ AI 7 350 (Up to 5.0GHz, 8-core
16-thread)

Overkill
Ryzen™ AI 9 HX 370 (Up to 5.1GHz, 12-core
24-thread)

Up to 50 TOPS

Performance - 45W sustained, 54W boost
Balanced - 40W sustained, 48W boost
Efficiency - 30W sustained, 36W boost

Mainboard
Honeywell PTM7958 phase change thermal interface for processor
Two 6.0mm and one 8.0mm heatpipes

Expansion Bay Shell
75.0 × 75.0 × 8.5mm dual fans

Graphics Module
Honeywell PTM7958 phase change thermal interface
Four 10mm heatpipes
75.0 × 75.0 × 11.5mm dual fans

Ryzen™ AI 7 350
AMD Radeon™ 860M
Up to 3.0GHz
8 graphics cores

Ryzen™ AI 9 HX 370
AMD Radeon™ 890M
Up to 2.9GHz
16 graphics cores

NVIDIA® GeForce RTX™ 5070 Laptop GPU
798 AI TOPS
Up to 100W TGP (on AC)
Up to 50W TGP (on battery)
8GB GDDR7 memory
128-bit memory bus
384GB/s memory bandwidth
2.0GHz base clock and up to 2.4GHz boost
USB-C port with DP Alt Mode and charging
4,608 CUDA cores
DLSS 4
5th gen tensor cores
4th gen ray tracing
1x 9th gen NVIDIA encoder
1x 6th gen NVIDIA decoder

Performance
Windows 11 Home (Copilot+ enabled)

Performance Pro
Windows 11 Pro (Copilot+ enabled)

Overkill
Windows 11 Pro (Copilot+ enabled)

Performance
512GB SSD (SN8000S)

Performance Pro
1TB SSD (SN8000S)

Overkill
2TB SSD (SN8000S)

n/a

Note: The secondary storage interface supports x2 PCIe 4.0. SSDs with x4 PCIe 4.0 will run at slower speed.

Performance
16GB (2 x 8GB) DDR5-5600

Performance Pro
32GB (2 x 16GB) DDR5-5600

Overkill
64GB (2 x 32GB) DDR5-5600

AMD RZ717 Wi-Fi 7 module using an M.2 connector for high-speed wireless connectivity

With Expansion Bay Shell:
Height: 17.95mm
Width: 356.58mm
Depth: 270.00mm
Weight: 2.10kg

With Graphics Module:
Height: 20.95mm
Width: 356.58mm
Depth: 290.20mm
Weight: 2.40kg

CNC aluminum Top Cover
Magnesium alloy thixomolded Bottom Cover
155° Hinges with 6.1kg force profile

16" 16:10 anti-glare matte display (2560x1600)

165Hz refresh rate
VRR & FreeSync
G-Sync support - requires NVIDIA® GeForce RTX™ 5070 Laptop GPU and Display Kit (2nd gen)
9ms rise + fall time
1500:1 contrast
100% DCI-P3
500nit brightness

Stereo Bi-amp speakers with 1W high frequency driver and 2W wide band driver, powered by an ALC1318 smart amp
2x MEMS microphones with hardware privacy switches

6x user-selectable Expansion Cards

Slot 1 and 4:
USB 4
Display Output (DP 2.1 UHBR10)
Up to 240W charging
USB-A (Higher power consumption)

Slot 2 :
USB 3.2
Display Output (DP 2.1 UHBR10)
Up to 240W charging
USB-A

Slot 3 and 6:
USB 3.2
USB-A

Slot 5 :
USB 3.2
Display Output (DP 1.4 HBR3)
Up to 240W charging
USB-A

---

Framework Laptop 16 Graphics Module (NVIDIA® GeForce RTX™ 5070 Laptop GPU) USB-C port capabilities

USB 2.0
Display Output (DP 2.1)
Up to 240W charging

---

Framework Laptop 16 Graphics Module (Radeon™ RX 7700S) USB-C port capabilities

USB 2.0
Display Output (DP 2.1)

6x user-selectable Expansion Cards: USB-C, USB-A, HDMI, DP, Ethernet, 250GB, 1TB, MicroSD, SD, Audio

PCIe x8 interface enables a range of graphic and non-graphics use cases that need both high power and high speed

85Wh
80% capacity at 1000 cycles

1080p 30fps with Omnivision OV08X 9.2MP image sensor and 87 degree field of view 5 element lens, with hardware privacy switch

Fingerprint Reader compatible with Windows Hello and libfprint in Linux

240W GaN USB-C

Black

All Keyboards are hot-swappable, backlit with 1.5mm key travel, run QMK firmware, and support NKRO
Available in both RGB and white backlit options
US English layout with a Copilot key is also available

122.6mm x 76.6mm Windows Precision Touchpad with matte glass surface

75% post-industrial recycled aluminum top cover
90% post-industrial recycled magnesium aluminum bottom cover
30-35% post-consumer recycled plastic content
Fully carbon-offset shipping
100% recyclable packaging
Carbon capture available in the Framework Marketplace

Framework Laptop 16
Keyboard
Spacers, Numpad, or Macropad
Power Adapter
Expansion Cards (customizable)
Framework Screwdriver

⚠️ WARNING: This product can expose you to chemicals including Nickel (Metallic), which is known to the State of California to cause cancer, and Bisphenol A (BPA), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.

Easy to repair with replacement parts available in the Framework Marketplace

1-year limited warranty

2023

Starting at $1,299

• Build it yourself
• Setup Time: 10-20 minutes
• Difficulty: Moderate

AMD Ryzen™ 7 7840HS
Up to 5.1GHz
8 Cores
16-Thread
24MB Cache

AMD Ryzen™ 9 7940HS
Up to 5.2GHz
8 Cores
16Threads
24MB Cache

45W continuous processor power

(current production) Honeywell PTM7958 phase change thermal interface for processor
(earlier production) Liquid metal thermal interface for processor

AMD Ryzen™ 7 7840HS
Radeon™ 780M Graphics

AMD Ryzen™ 9 7940HS
Radeon™ 780M Graphics

None (use integrated graphics)

Radeon™ RX 7700S
32 compute units
up to 100W TGP (on AC)
8GB 18Gbps GDDR6 memory
USB-C port with DP Alt Mode

None (bring your own)

Check out our recommended Linux Distros

Choose up to WD_BLACK™ SN850X NVMe™- M.2 2280 - 8TB
SSDs or bring your own.

Choose up to 2TB WD_BLACK™ NVMe™ M.2 2230 SSDs or bring your own.

Choose up to 96GB DDR5-5600 or bring your own.

AMD RZ616 Wi-Fi 6E

With Expansion Bay Shell:
Height: 17.95mm
Width: 356.58mm
Depth: 270.00mm
Weight: 2.10kg

With Graphics Module:
Height: 20.95mm
Width: 356.58mm
Depth: 290.20mm
Weight: 2.40kg

CNC aluminum Top Cover
Magnesium alloy thixomolded Bottom Cover
155° Hinges with 6.1kg force profile

16" 16:1- Anti-glare matte display (2560x1600)

165 Hz refresh rate
VRR & FreeSync
G-Sync Support (NVIDIA® GeForce RTX™ 5070 and Display Module (2nd gen)
9ms rise + fall time
1500:1 contrast
100% DCI-P3
500 nit brightness

Stereo Bi-amp speakers with 1W high frequency driver and 2W wide band driver, powered by an ALC1318 smart amp
2x MEMS microphones with hardware privacy switches

6x user-selectable Expansion Cards

Slot 1 and 4:
USB 4
Display Output
Up to 240W charging
USB-A (Higher power consumption)

Slot 2:
USB 3.2
Display Output
Up to 240W charging
USB-A

Slot 3 and 6:
USB 3.2
USB-A

Slot 5:
USB 3.2
Up to 240W charging
USB-A

6x user-selectable Expansion Cards: USB-C, USB-A, HDMI, DP, Ethernet, 250GB, 1TB, MicroSD, SD, Audio

PCIe x8 interface enables a range of graphic and non-graphics use cases that need both high power and high speed

85Wh
80% capacity at 1000 cycles

1080p 60fps webcam with hardware privacy switch

Fingerprint Reader compatible with Windows Hello and libfprint in Linux

180W GaN USB-C

Black
Orange
Lavender

All Keyboards are backlit with 1.5mm key travel, run QMK firmware and support NKRO

122.6mm x 76.6mm Windows Precision Touchpad with matte glass surface

75% post-industrial recycled aluminum top cover
90% post-industrial recycled magnesium aluminum bottom cover
30-35% post-consumer recycled plastic content
Fully carbon-offset shipping
100% recyclable packaging
Carbon capture available in the Framework Marketplace

Framework Laptop 16 DIY Edition
Keyboard
Spacers, Numpad, or Macropad
Bezel
Memory (optional)
Storage (optional)
Expansion Cards (customizable)
Power Adapter (optional)
Framework Screwdriver

⚠️ WARNING: This product can expose you to chemicals including Nickel (Metallic), which is known to the State of California to cause cancer, and Bisphenol A (BPA), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.

Easy to repair with replacement parts available in the Framework Marketplace.

1-year limited warranty

2023

Starting at $1,799

Ready to use
Setup time: 5-10 minutes
Difficulty: Easy

Performance
AMD Ryzen™ 7 7840HS (up to 5.1GHz, 8-Core
16-Thread, 24MB Cache)

Performance Pro
AMD Ryzen™ 7 7840HS (up to 5.1GHz, 8-Core
16-Thread, 24MB Cache)

Overkill
AMD Ryzen™ 9 7940HS (up to 5.2GHz, 8-Core
16-Thread, 24MB Cache)

45W continuous processor power

(current production) Honeywell PTM7958 phase change thermal interface for processor
(earlier production) Liquid metal thermal interface for processor

AMD Ryzen™ 7 7840HS
Radeon™ 780M Graphics

AMD Ryzen™ 9 7940HS
Radeon™ 780M Graphics

None (use integrated graphics)

Radeon™ RX 7700S
32 compute units
up to 100W TGP (on AC)
8GB 18Gbps GDDR6 memory
USB-C port with DP Alt Mode

Performance
Windows 11 Home

Performance Pro
Windows 11 Pro

Overkill
Windows 11 Pro

n/a

n/a

Performance
16GB (2 x 8GB) DDR5-5600

Performance Pro
16GB (2 x 8GB) DDR5-5600

Overkill
32GB (2 x 16GB) DDR5-5600

AMD RZ616 Wi-Fi 6E

With Expansion Bay Shell:
Height: 17.95mm
Width: 356.58mm
Depth: 270.00mm
Weight: 2.10kg

With Graphics Module:
Height: 20.95mm
Width: 356.58mm
Depth: 290.20mm
Weight: 2.40kg

CNC aluminum Top Cover
Magnesium alloy thixomolded Bottom Cover
155° Hinges with 6.1kg force profile

16" 16:1- Anti-glare matte display (2560x1600)

165 Hz refresh rate
VRR & FreeSync
9ms rise + fall time
1500:1 contrast
100% DCI-P3
500 nit brightness

Stereo Bi-amp speakers with 1W high frequency driver and 2W wide band driver, powered by an ALC1318 smart amp
2x MEMS microphones with hardware privacy switches

6x user-selectable Expansion Cards

Slot 1 and 4:
USB 4
Display Output
Up to 240W charging
USB-A (Higher power consumption)

Slot 2:
USB 3.2
Display Output
Up to 240W charging
USB-A

Slot 3 and 6:
USB 3.2
USB-A

Slot 5:
USB 3.2
Up to 240W charging
USB-A

6x user-selectable Expansion Cards: USB-C, USB-A, HDMI, DP, Ethernet, 250GB, 1TB, MicroSD, SD, Audio

PCIe x8 interface enables a range of graphic and non-graphics use cases that need both high power and high speed

85Wh
80% capacity at 1000 cycles

1080p 60fps webcam with hardware privacy switch

Fingerprint Reader compatible with Windows Hello and libfprint in Linux

180W GaN USB-C

Black

All Keyboards are backlit with 1.5mm key travel, run QMK firmware and support NKRO

122.6mm x 76.6mm Windows Precision Touchpad with matte glass surface

75% post-industrial recycled aluminum top cover
90% post-industrial recycled magnesium aluminum bottom cover
30-35% post-consumer recycled plastic content
Fully carbon-offset shipping
100% recyclable packaging
Carbon capture available in the Framework Marketplace

Framework Laptop 16
Keyboard
Spacers, Numpad, or Macropad
Power Adapter
Expansion Cards (customizable)
Framework Screwdriver

⚠️ WARNING: This product can expose you to chemicals including Nickel (Metallic), which is known to the State of California to cause cancer, and Bisphenol A (BPA), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.

Easy to repair with replacement parts available in the Framework Marketplace.

1-year limited warranty
