2025

Starting at $549

• Build it yourself
• Setup Time: 10 - 20 minutes
• Difficulty: Moderate

i3-1315U
Up to 4.5GHz
2 Performance-cores
4 Efficient-cores
8 total threads

i5-1334U
Up to 4.6GHz
2 Performance-cores
8 Efficient-cores
12 total threads

Performance mode - 15W sustained 40W boost
Balanced mode - 15W sustained 40W boost
Efficiency mode - 15W sustained 20W boost

Thermals 64 x 5.5mm cooling fan
Single 8mm heat pipe
Honeywell PTM7958 thermal paste

i3-1315U
Intel® UHD Graphics
Up to 1.25GHz
64 Execution Units

i5-1334U
Intel® UHD Graphics
Up to 1.25GHz
80 Execution Units

None (bring your own)

Check out our recommended Linux Distros

1x M.2 2230 NVMe™ SSD slot

Choose up to 2TB Western Digital NVMe™ SSDs or bring your own

1x SO-DIMM slot supports up to 48GB DDR5 (running at DDR5-5200 speeds)

Choose up to 48GB DDR5 or bring your own

Intel AX211 Wi-Fi 6E

1.3kg

18.45 x 287.00 x 213.88mm

12.2" LCD, 16:10 aspect ratio
1920 x 1200 resolution
60Hz refresh rate
>400nit brightness
50% NTSC color gamut
1500:1 typical contrast ratio
DC Dimming
MPP 2.0 and USI 2.0 stylus support
Soda-lime glass

4x user-selectable Expansion Cards

3.5mm combo headphone jack

Available ports and storage: USB-C, USB-A, HDMI, DisplayPort, Ethernet, 250GB, 1TB, MicroSD, SD

Supporting USB 3.2 Gen 2, USB-PD, DisplayPort Alt Mode

Stereo 2W speakers, dual high-sensitivity 67dBA SNR MEMS microphones with hardware privacy switch

Built-in 3.5mm combo headphone jack

50Wh

1080p 30fps with Omnivision OV02C 2MP image sensor and 80 degree field of view 5 element lens, with hardware privacy switch

None

60W GaN USB-C (optional, bring your own)

Full size (19mm key spacing), non-backlit, 1.5mm key travel

Dimensions: 10 x 165mm

Weight: 15g

Charging: USB-C (non-PD 5V) with charging indicator

Battery: Removable, rechargeable 80mAh Li-ion

Tilt sensitivity: 60-degree tilt sensitivity

Pressure level: 4096

Compatibility: Supports USI 2.0

Buttons: 2 programmable buttons

360-degree hinge

Chassis made of overmolded shock-absorbing TPU over plastic with an inner metal structure

30% Post-consumer recycled plastic resin: Top Cover, Input Cover, Bottom Cover, Hinge Cap

35% Post-consumer recycled plastic resin: Display Cover, Camera/Mic Button, Expansion Card Latch

Fully carbon-offset shipping

100% recyclable packaging

Carbon capture available in the Framework Marketplace

Framework Laptop 12 DIY Edition
Input Cover
Memory (optional)
Storage (optional)
Expansion Cards (customizable)
Power Adapter (optional)
Stylus (optional)
Framework Screwdriver

⚠️ WARNING: This product can expose you to chemicals including Nickel (Metallic), which is known to the State of California to cause cancer, and Bisphenol A (BPA), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov

Easy to repair with replacement parts available in the Framework Marketplace

1 Year Framework Limited Warranty
